Maruti-Suzuki-Ertiga-Arena Pillai Needamangalam, Thiruvarur

Car Range

Alto K10

Safety
Infotainment
Comfort & Convenience
Exteriors
Interiors

Safety

	STD MT	LXI MT	LXI CNG	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Rear Door Child lock
Engine Immobiliser
Speed Sensing Auto Door Lock
Central Door Locking
Impact Sensing Door Unlock
High Speed Alert^{^}
Front Seat Belts Pre-Tensioner & Force Limiter
Rear Seat Belt Center(2-Point Static)		(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)
Rear Seat Belt Outboard(3-Point)	(Static)	(Static)	(Static)	(ELR)	(ELR)	(ELR)	(ELR)	(ELR)
Dual Front Airbags^##
ABS with EBD
Reverse Parking Sensor
Seat Belt Reminder with Buzzer (Front & Rear Seat)
HEARTECT Platform
Headlamp Levelling
High-Mounted Stop Lamp
Collapsible Steering Column
^The speed warning for alert of over-speed to driver. When vehicle speed exceeds about 80 km/h primary level warning with two beeps will sound every minute. When the vehicle speed exces level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume if the vehicle is slowed down to about 28 km This buzzer does not indicate any malfunction in vehicle.
##For details on functioning of safety features, including airbag, kindly refer to the owner's manual

Infotainment

	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Touch Screen Audio				17.78 cm (SmartPlay Studio)	17.78 cm (SmartPlay Studio)
Media Receiver (AM/FM/Bluetooth)	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
AUX Port
USB Port
Remote Application
Bluetooth
Android Auto
Apple Carplay
Speakers	2	2	2	4	4
Steering Mounted Audio & Voice Control
Digital Speedometer
Distance to Empty	^{*^}	^{*^}	^{*^}
Fuel Consumption - Average	^{*^}	^{*^}	^{*^}
Fuel Consumption - Instantaneous	^{*^}	^{*^}	^{*^}
Gear Shift Indicator (MT only)	(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)
Gear Position Indicator (AGS only)
Low Fuel Warning	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Door Ajar Warning	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Key off/Head lamp on Reminder
*^For VXI CNG variant, fuel consumption related data available only in Petrol Mode.
*^Availble only in VXi/VXi+variants as a limited edition till stock lasts.

Comfort & Convenience

	STD MT	LXI MT	LXI CNG	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Cabin Air Filter
Front Power Windows
Internally Adjustable ORVMs
Remote Keyless Entry
Remote Back Door Opener
Remote Fuel Lid Opener
Accessory Socket
Air Conditioner with Heater
Power Steering

Exteriors

	STD MT	LXI MT	LXI CNG	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Roof Antenna
Body Coloured Bumpers
Body Coloured Outside Door Handles
Wheel Covers	Center Cap	Center Cap	Center Cap	Full	Full	Full	Full	Full

Interiors

	STD MT	LXI MT	LXI CNG	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Sun Visor	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr
Rear Parcel Tray
Assist Grips	Co- Dr.	Co- Dr.	Co- Dr.	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear
Front console utility space
1L Bottle Holder in Front doors with Map Pockets
Silver Accent Inside Door Handles
Silver Accent on Steering Wheel
Silver Accent on Side Louvers
Silver Accent on Center Garnish

Dimensions
Engine
Transmission
Suspension
Tyre
Brakes

Dimensions

	PETROL	CNG
Overall Length (mm)	3530	3530
Overall Width (mm)	1490	1490
Overall Height (Unladen) (mm)	1520	1520
Wheelbase(mm)	2380	2380
Turning Radius(m)	4.5	4.5
Seating Capacity	5 Persons	4 Persons
Boot Space(L)^#	214
#VDA method.

Engine

	PETROL	CNG
Engine Type	K10C	K10C CNG
Fuel type	Petrol	Petrol + CNG
Piston Displacement (cc)	998	998
Maximum Power (kW@rpm)	49 kW @ 5500 rpm	41.7 kW @ 5300 rpm (CNG Mode) 48 kW @ 5500 rpm (Petrol Mode)
Maximum Torque (Nm@rpm)	89 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG Mode) 89 Nm @ 3500 rpm (Petrol Mode)
Emission Standard	BS VI	BS VI
Fuel Tank Capacity(L)	27	27 (Petrol Mode) 55 (CNG Mode) (Water Equivalent)

Transmission

	PETROL	CNG
Transmission Type	5MT/AGS	5MT

Suspension

	PETROL	CNG
Front	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring

Tyre

	PETROL	CNG
Tyre Size	145/80 R13	145/80 R13

Brakes

	PETROL	CNG
Front	Disc	Disc
Rear	Drum	Drum

Celerio

Exteriors
Interiors
Comfort and Convenience
Central Console & Instrument Panel
Safety & Security
New Technology

Exteriors

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
ORVM with Turn Indicators
Front Fog Lamps
Body Coloured Bumper
Body Coloured ORVMs
Body Coloured Outside Door Handles
Chrome accent on front grille
B Pillar Black Out Tape
Full Wheel Covers	(Center cap)
15" (38.02cm) Alloy Wheels

Interiors

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Co-Dr Vanity Mirror in Sun Visor
Dr. Side Sunvisor with ticket holder
Day Night IRVM
Front Cabin Lamp (3 Positions)
Bottle Holder	6	6	6	6	6	6	6	6
Driver Seat Height Adjuster
Front Seat Back Pockets (Passenger Side)
Rear Seat (60:40 split)
Front and Rear Headrest	Integrated	Integrated	Integrated	Integrated	Integrated	Integrated	Integrated	Integrated
Rear Parcel Shelf

Comfort &Convenience

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Air Conditioner(Manual)
Pollen Filter
Engine Push Start/Stop with Smart Key
Smartplay Studio System with Smartphone Navigation and Voice Command (Android Auto and Apple CarPlay enabled)
Smart Play Dock - USB, FM, AUX, BT
No. of Speakers				4	4		4	4
Remote keyless Entry
Security System
Central Door Lock (5 Doors)
Power Windows		Fr/Rr	Fr/Rr	Fr/Rr	Fr/Rr	Fr/Rr	Fr/Rr	Fr/Rr
Power Windows - Auto Down (Driver Side)
Outside Mirror Types	Flap Type	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable	Electrically Adjustable
Electrically-Foldable ORVM
Steering- Mounted Audio Controls
Steering-Mounted Voice Control
Power Steering

Central Consol & Instrument Panel

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Illumination Colour	Amber	Amber	Amber	Amber	Amber	Amber	Amber	Amber
Tachometer
Urethane Steering Wheel
Tilt Steering
Accessory Socket
Dial-Type Climate Control	Black	Silver Painted	Silver Painted	Silver Painted	Silver Painted	Silver Painted	Silver Painted	Silver Painted
Fuel Consumption (Instantaneous and avg.)
Distance to Empty
Gear Position Indicator
Gear Shift Indicator
Door Ajar Warning Lamp
Headlamp Warning
Low Fuel Warning
Key Off/Headlamp on Reminder

Safety & Security

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Driver Airbag^##
Passenger Airbags^##
Seat Belt Reminder with Buzzer (Front + Rear Seat)^**#
Seat Belt Pre-Tensioner & Force Limiters (Dr. + Co-Dr.)
Seat Belt for all Seats
Hill Hold Assist
Impact-Sensing Auto Door Unlock
Pedestrian Protection
ABS with EBD
ESC
Speed-Sensitive Auto Door Lock
Headlight Leveling
Rear Window Wiper & Washer
Front Ventilated Disc
Immobilizer
Child-Proof Rear Door Locks
Rear Defogger
Speed Alert System^
Reverse Parking Assist Sensors
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
**#Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^The speed alert system gives audible warning for alert of over-speed to driver. When Vehicle speed exceeds 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.

New Technology

	LXi MT	VXi MT	VXi CNG	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS
Engine Idle Start Stop		(Petrol)	(Petrol)
Hill Hold Assist

Dimensions (in mm)
Engine
Transmission
Suspension System
Weight(kg)
Capacity
Power Steering
Tyres
Brakes

Dimensions

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Overall Length	3695	3695	3695	3695	3695	3695	3695	3695
Overall Width	1655	1655	1655	1655	1655	1655	1655	1655
Overall Height	1555	1555	1555	1555	1555	1555	1555	1555
Wheelbase	2435	2435	2435	2435	2435	2435	2435	2435
Tread Front	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)	1430(R14), 1440(R15)
Tread Rear	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)	1440(R14), 1450(R15)

Engine

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Type	K10C	K10C	K10C	K10C	K10C	K10C	K10C	K10C CNG
Capacity	998cc	998cc	998cc	998cc	998cc	998cc	998cc	998cc
Engine Type	Aluminium	Aluminium	Aluminium	Aluminium	Aluminium	Aluminium	Aluminium	Aluminium
Number of Cylinders	3	3	3	3	3	3	3	3
Number of Valves in Each Cylinder	4	4	4	4	4	4	4	4
Maximum Output	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	49kW (66.62Ps) @ 5500rpm	CNG Mode: 41.7kW (56.70Ps) @ 5300rpm Gasoline Mode: 48kW (65.26Ps) @ 5500rpm
Maximum Torque	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	89Nm @ 3500rpm	CNG Mode: 82.1Nm @ 3400rpm Gasoline Mode: 89Nm @ 3500rpm
Emmision Standard Type	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II	BS VI + OBD II
Accelerator Pedal Type	Electric Type	Electric Type	Electric Type	Electric Type	Electric Type	Electric Type	Electric Type	Electric Type

Transmission

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Type	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT/Auto Gear Shift	5MT

Suspension System

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Front	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring

Weight(kg)

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Kerb Weight	800kg	810kg	810kg	820kg	815kg	820kg	825kg	905kg
Gross Vehicle Weight	1260	1260	1260	1260	1260	1260	1260	1320

Capacity

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Seating Capacity \| Persons	5	5	5	5	5	5	5	5
Luggage Capacity (L)	313***	313***	313***	313***	313***	313***	313***
Fuel Tank Capacity (L)	32	32	32	32	32	32	32	Petrol:32 CNG:60(Water Equivalent)
***VDA Method

Power Steering

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Type	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering	Electric Power Steering

Tyres

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Tyre Size**	165/70R14	165/70R14	165/70R14	175/60R15	165/70R14	165/70R14	175/60R15	165/70R14
**Spare wheel material is steel (for all variants) and tyre size is 165/70 R14.

Brakes

	LXi MT	VXi MT	ZXi MT	ZXi+ MT	VXi AGS	ZXi AGS	ZXi+ AGS	VXi CNG
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Dzire

EXTERIOR
INTERIOR
SAFETY & SECURITY
INFOTAINMENT
COMFORT & CONVENIENCE

EXTERIOR

	LXI MT	VXI MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
R15 Alloys					(Painted)	(Painted)	(Painted)	(Precision Cut)	(Precision Cut)
R14 Steel Wheels
Full Wheel Covers
Sleek Line LED DRLs
LED Crystal Vision Headlamps
FocusBeam Projector Headlamps
Clarity Vision LED Fog Lamps
Chrome Finish - Front Grille
Chrome Finish - Trunk Lid Garnish
Side Turn Indicators on Outside Rear View Mirrors
Body Coloured Door Handles
Body Coloured Outside Rear View Mirrors
LED High Mount Stop Lamp
3D Trinity LED Rear Lamps Signature
Shark Fin Antenna
Aero Boot Lip Spoiler
Belt Line Garnish	Black	Black	Black	Black	Chrome	Chrome	Chrome	Chrome	Chrome

INTERIORS

	LXI MT	VXI MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Front Footwell Illumination
Leather Wrapped Steering Wheel with Urbane Satin Accent^
Urbane Satin Accents on Console, Door Trims
Chrome Finish - AC Vents
Chrome Finish - Inside Door Handles
Chrome Accent On Parking Brake Lever Tip And Gear Shift Knob
IP Ornament Finish		(Satin Silver)	(Satin Silver)	(Satin Silver)	(Satin Silver + Wood)	(Satin Silver + Wood)	(Satin Silver + Wood)	(Satin Silver + Wood)	(Satin Silver + Wood)
Front Dome Lamp								(spot lamp)	(spot lamp)
Centre Room Lamp
Co. Driver Side Sunvisor with Vanity Mirror	(without mirror)
Driver Side Sunvisor with Ticket Holder	(without holder)
Front Door Armrest with Fabric
Dual-Tone Sophisticated Interiors ( Black & Beige)
Outside Temperature Display		AMT Only	AMT Only	AMT Only
Speedometer with Tachometer
Low-Fuel Warning Lamp
Multi-Information Display								(Coloured)	(Coloured)
^Some parts of the leather-appointed upholstery will contain man-made material.

SAFETY & SECURITY

	LXI MT	VXI MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Reverse Parking Camera
360 View Camera (HD)
Anti-Theft Security System (Shock Sensor)
Tyre Pressure Monitoring System (TPMS)
Day/Night Adjustable Inside Rear View Mirror
Speed-Sensitive Auto Door Locking
Rear Defogger
Engine Immobilizers
6 Airbags (Front, Side and Curtain)^^
High-Speed Warning Alert^#
3-Point seat belts for all Seats
Seat Belt Reminder Lamp & Buzzer (all occupants)^^^
Suzuki HEARTECT Body
Electronic Stability Program (ESP)
Hill Hold Assist
ABS with EBD
Reverse Parking Sensors
ISOFix Child Seat Anchorages
Front Seat Belt with Pre-Tensioner & Force Limiter
^^For details on the functioning of safety features, including airbags, kindly refer to the Owner's Manual.
#If the vehicle's speed exceeds 80 km/h, then the primary level warning will beep twice every minute. And, if the speed goes above 120 km/h, the secondary level warning will keep beeping. If the vehicle's speed slows down to 118 km/h, the primary warning will resume. If the vehicle is slowed down to 78 km/h, the speed alert warning will stop. This buzzer does not indicate any malfunction in the vehicle.

INFOTAINMENT

	VXI MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
SmartPlay Pro+ with 22.86 cm Touchscreen
Surround Sense Powered by Arkamys
SmartPlay Pro with 17.78 cm Touchscreen
Android Auto and Apple CarPlay^###	Wireless	Wireless	Wireless	Wireless	Wireless	Wireless	Wireless	Wireless
Remote Control App for Infotainment
Steering Mounted Audio & Calling Controls
Over The Air Updates (OTA) using Smartphone
Onboard Voice Assistant (Wake-up Through "Hi Suzuki" with Barge-in Feature)
USB & Bluetooth Connectivity
Speakers (4 nos.)
Tweeters (2 nos.)
###Apple and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature- availability/# applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link: http://www.apple.com/ios/ carplay. Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Map™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link: https://www.android.com/auto/ #hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/ #6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc. ^Some parts of the leather-appointed upholstery will contain man-made material.

COMFORT & CONVENIENCE

	LXI MT	VXI MT	VXI AMT	VXI CNG MT	ZXI MT	ZXI AMT	ZXI CNG MT	ZXI+ MT	ZXI+ AMT
Electric Sunroof
Rear Reading Lamps
Cruise Control
Wireless Charger
Engine Push Start-Stop Button with Smart Key
Auto headlamps with Follow Me Home & Lead Me to Vehicle
Key-fob operated Trunk opening
Luggage Room Lamp
Rear AC Vent
Rear Seat Center Armrest with Cup Holder
Front USB (Type A)
Rear Fast Charging USB (Type A and C) with phone pocket
Electrically Adjustable Outside Rear View Mirrors
Electrically Foldable Outside Rear View Mirrors								(Auto fold on locking)	(Auto fold on locking)
Height Adjustable Driver Seat
Adjustable Rear Seat Headrests
Gear Position Indicator (AMT Only)
Gear Shift Indicator (MT Only)
Power Windows (Front + Rear)
Electromagnetic trunk opening
Adjustable Front Seat Headrests
Auto Up Down and Pinch Guard Power Window (Driver)
Driver Side Footrest
Front Accessory Socket
Remote Keyless Entry System
Central Locking
Power & Tilt Steering
Bottle Holder on All Doors
Digital Air Conditioner with Panel Illumination	(Manual)	(Manual)	(Manual)	(Manual)	(Auto)	(Auto)	(Auto)	(Auto)	(Auto)

DIMENSION
ENGINE
TRANSMISSION
WEIGHT
BRAKES
SUSPENSION
TYRES

DIMENSIONS

	LXI MT	VXI MT	VXI AMT	ZXI MT	ZXI AMT	ZXI+ MT	ZXI+ AMT	VXI CNG MT	ZXI CNG MT
Length (mm)	3995	3995	3995	3995	3995	3995	3995	3995	3995
Width (mm)	1735	1735	1735	1735	1735	1735	1735	1735	1735
Height (mm)	1525	1525	1525	1525	1525	1525	1525	1525	1525
Wheelbase(mm)	2450	2450	2450	2450	2450	2450	2450	2450	2450
Turning Radius (m)	4.8	4.8	4.8	4.8	4.8	4.8	4.8	4.8	4.8
Ground clearance (mm) (unladen)	163	163	163	163	163	163	163	163	163
Seating Capacity	5	5	5	5	5	5	5	5	5
Boot Space (L)	382	382	382	382	382	382	382

ENGINE

	LXI MT	VXI MT	VXI AMT	ZXI MT	ZXI AMT	ZXI+ MT	ZXI+ AMT	VXI CNG MT	ZXI CNG MT
Engine Type	Z12E	Z12E	Z12E	Z12E	Z12E	Z12E	Z12E	Z12E	Z12E
Fuel Type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol + CNG (Bi-Fuel)	Petrol + CNG (Bi-Fuel)
Engine Capacity (cc)	11197	1197	1197	1197	1197	1197	1197	1197	1197
Max Power (kW @rpm)	60 kW / 81.58 Ps @ 5700 rpm	60 kW / 81.58 Ps @ 5700 rpm	60 kW / 81.58 Ps @ 5700 rpm	60 kW / 81.58 Ps @ 5700 rpm	60 kW / 81.58 Ps @ 5700 rpm	60 kW / 81.58 Ps @ 5700 rpm	60 kW / 81.58 Ps @ 5700 rpm	51.3 kW / 69.75 Ps @ 5700 rpm	51.3 kW / 69.75 Ps @ 5700 rpm
Max Torque (Nm @ rpm)	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	101.8 Nm @ 2900 rpm	101.8 Nm @ 2900 rpm
Emission Type	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI
Fuel Efficiency	24.79 km/l MT 25.71 km/l AMT	24.79 km/l MT 25.71 km/l AMT	24.79 km/l MT 25.71 km/l AMT	24.79 km/l MT 25.71 km/l AMT	24.79 km/l MT 25.71 km/l AMT	24.79 km/l MT 25.71 km/l AMT	24.79 km/l MT 25.71 km/l AMT	33.73 km/kg	33.73 km/kg
Fuel Tank Capacity (L)	37L	37L	37L	37L	37L	37L	37L	Petrol: 37L CNG: 55L (water equivalent)	Petrol: 37L CNG: 55L (water equivalent)
Idle Start Stop

TRANSMISSION

	LXI MT	VXI MT	VXI AMT	ZXI MT	ZXI AMT	ZXI+ MT	ZXI+ AMT	VXI CNG MT	ZXI CNG MT
Transmission	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT/5AMT	5MT	5MT

WEIGHT

	LXI MT	VXI MT	VXI AMT	ZXI MT	ZXI AMT	ZXI+ MT	ZXI+ AMT	VXI CNG MT	ZXI CNG MT
Kerb Weight (kg)	920-960 kg	920-960 kg	920-960 kg	920-960 kg	920-960 kg	920-960 kg	920-960 kg	1020-1025 kg	1020-1025 kg
Gross Vehicle Weight (kg)	1375 kg	1375 kg	1375 kg	1375 kg	1375 kg	1375 kg	1375 kg	1435 kg	1435 kg

Brakes

	LXI MT	VXI MT	VXI AMT	ZXI MT	ZXI AMT	ZXI+ MT	ZXI+ AMT	VXI CNG MT	ZXI CNG MT
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

SUSPENSION

	LXI MT	VXI MT	VXI AMT	ZXI MT	ZXI AMT	ZXI+ MT	ZXI+ AMT	VXI CNG MT	ZXI CNG MT
Front	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut	Mac Pherson Strut
Rear	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam

TYRES

	LXI MT	VXI MT	VXI AMT	ZXI MT	ZXI AMT	ZXI+ MT	ZXI+ AMT	VXI CNG MT	ZXI CNG MT
Tyre Size (Steel)	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14	165/80 R14
Tyre Size (Alloy)	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15

Eeco

Comfort
Instrument Panel & Console
Interior
Exterior
Safety & Security
Facilities On Board

Comfort

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Air Conditioner
Heater
Reclining Front Seats
Sliding Driver Seat
Head Rest-Front Row	Integrated	Integrated	Integrated	Integrated	Integrated	Integrated
Head Rest-Second Row	Fixed, Pillow	Fixed, Pillow	Fixed, Pillow	Fixed, Pillow
Head Rest-Third Row				Fixed, Pillow
Seat Back Pocket (Co-Driver Seat)
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Instrument Panel & Console

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Illuminated Hazard Switch
Digital Display in Instrument Cluster
12 Volt Accessory Socket
Multi Tripmeter
Digital Speedometer
Dome Lamp Battery Saver Function
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Interior

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Cabin Air Filter
Both Side Sunvisor
Assist Grip (Co-Driver + Rear)
Molded Roof Lining
Molded Floor Carpet
Dual Interior Color
Seat Matching Interior Color
Front Cabin Lamp
Rear Cabin Lamp
Steering Lock
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Exterior

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Wheel Cover	Center Cap	Center Cap	Center Cap	Center Cap	Center Cap	Center Cap
Front Mud Flaps
Outside Rear View Mirror (Left & Right)
Ambulance Decal - Front & Rear
Partly Frosted Rear side windows
Partly Frosted Back Door windows
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Safety & Security

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Immobilizer
Headlamp Leveling
Side Impact Beams
Child Lock for Sliding Doors & Windows
Offset Crash (as per AIS 098)^**
Seat Belts for all Seats
High Mount Stop Lamp
Reverse Parking Sensor System
Seat Belt Reminder (Dr + Co-Dr)
Speed Alert System
ABS with EBD
Dual Airbag
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
**Crash Compliance is with Offset Crash (as per AIS 098).

Facilities On Board

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Revolving Roof Lamp
Molded Rubber Matting in Rear Cabin
Siren
Public Address System (Amplifier, Mike and Speaker)
Two LED lights inside Rear Cabin for Illuminated
Stretcher Assembly (Monoblock Stretcher)
Attendant's Seat
Space for First Aid and Nursing Kit
Oxygen Cylinder Clamp
Hook for Infusion Mounting
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Dimension & Weight
Engine (Petrol and CNG)
Transmission
Brake/Chassis

Dimension & Weight

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Fuel Efficiency	19.71 km/l	19.71 km/l	26.78 km/kg	19.71 km/l
Kerb Weight (kg)	935	935	1050	935	1030	940
Full Length (mm)	3675	3675	3675	3675	3675	3675
Full Width (mm)	1475	1475	1475	1475	1475	1475
Full Height (mm) Unladen	1825	1825	1825	1825	1930 (excluding top light)	1930 (excluding top light)
Seating Capacity	5	5	5	7	3+1 (Patient)	3 (with recommended seating capacity of 3 person + 1 patient after fabrication)
Tread Front (mm)	1280	1280	1280	1280	1280	1280
Tread Rear (mm)	1290	1290	1290	1290	1290	1290
Wheelbase (mm)	2350	2350	2350	2350	2350	2350
Minimum Turning Radius (m)	4.5	4.5	4.5	4.5	4.5	4.5
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Engine(Petrol and CNG)

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Engine Type	K12N	K12N	K12N	K12N	K12N	K12N
Engine Displacement(CC)	1197	1197	1197	1197	1197	1197
Max. Output(kw/rpm)	59.4/6000 (Gasoline)	59.4/6000 (Gasoline)	59.4/6000 (Gasoline) 52.7/6000 (CNG)	59.4/6000 (Gasoline)	59.4/6000 (Petrol)	59.4/6000 (Petrol)
Max. Torque(Nm/rpm)	104.4/3000 (Gasoline)	104.4/3000 (Gasoline)	104.4/3000 (Gasoline) 95/3000 (CNG)	104.4/3000 (Gasoline)	104.4/3000 (Petrol)	104.4/3000 (Petrol)
Tank Capacity	32 L	32 L	65 L	32 L	32 L	32 L
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Transmission

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Petrol & CNG	5MT	5MT	5MT	5MT	5MT	5MT
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Brake/Chassis

	5 Seater Standard	5 Seater AC	5 Seater AC CNG	7 Seater Standard	Ambulance	Ambulance Shell^*
Brake Front	Disc	Disc	Disc	Disc	Disc	Disc
Brake Rear	Drum	Drum	Drum	Drum	Drum	Drum
Front Suspension	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut
Tyre Size	155R13C 8PR	155R13C 8PR	155R13C 8PR	155R13C 8PR	155R13C 8PR	155R13C 8PR
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.

Ertiga

INTERIOR
EXTERIOR
INSTRUMENT CLUSTER
COMFORT & CONVENIENCE
INFOTAINMENT SYSTEM
SAFETY & SECURITY
**SUZUKI CONNECT

INTERIORS

	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG
Sculpted Dashboard with Metallic Teak - Wooden Finish
Metallic Teak-Wooden Finish on Door Trims (Fr.)
Premium Dual Tone Interiors
Height Adjustable Driver Seat
2nd Row 60:40 Split Seats with One Touch Recline & Slide
3rd Row 50:50 Split Seats with Recline function
Flexible luggage space with Flat Fold (3rd Row)	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)
Plush Dual-Tone Seat Fabric
Fr. Seat Back Pockets	Co-driver	Co-driver	Co-driver
Sliding Armrest with Utility Box (Front Row)
Leather Wrapped Steering Wheel with Metallic Teak-Wooden Finish
Adjustable Headrest (All Rows)
Split Type Luggage Board	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)	(Expect CNG)
Driver Side Sunvisor with Ticket Holder
Passenger Side Sunvisor with Vanity Mirror
Dazzle Chrome Tipped Parking Brake Lever
Gear Shift Knob with Dazzle Chrome Finish

EXTERIOR

	LXi MT	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
Rear Roof Spoiler
Projector Headlamps (Halogen)
3D Origami Style LED Tail Lamps
Dynamic Chrome Winged Front Grille	Painted	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome	Chrome
Floating Type Roof Design in Rear
Full Wheel Caps
Machined Two-tone Alloy Wheels^{^**}
Turn Signal Lamp Integrated in ORVMs
Back Door Garnish with Chrome Insert
Rear Wiper & Washer
Body Coloured Door Handles
Chrome Plated Door Handles
Body Coloured ORVMs

INSTRUMENT CLUSTER

	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG
MID With Coloured TFT
Tachometer
Gear Shift Indicator (MT)
Digital Clock
Outside Temperature Gauge
Fuel Consumption (Instantaneous and Avg)^##
Dedicated CNG Fuel Gauge	(CNG)	(CNG)	(CNG)	(CNG)	(CNG)	(CNG)
Total CNG Mode Time	(CNG)	(CNG)	(CNG)	(CNG)	(CNG)	(CNG)
Distance to Empty^##
Headlamp On Warning
Door Ajar Warning Lamp

COMFORT & CONVENIENCE

	LXi MT	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
Engine Push Start/Stop with Smart Key
Front Row AC	(Manual)	(Manual)	(Manual)	(Manual)	(Auto)	(Auto)	(Auto)	(Auto)	(Auto)
2nd Row AC Vents
3nd Row AC with 3 Stage Control
PM2.5 Filter
Front Twin Cup Holders (Console)
Rear Defogger
Remote Keyless Entry					(Smart Key)	(Smart Key)	(Smart Key)	(Smart Key)	(Smart Key)
Power Socket (12V) Front Row with Smartphone Storage Space
USB Charger 2nd Row (PD Type Max 60W) Type C + C
2nd Row Smart Phone Storage Space
USB Charger 3rd Row (PD Type Max 60W) Type C + C
Power Windows (Fr/Rr) with Dr. Side Auto Down Functions
Auto Window Up (Dr. Side with anti-pinch)
Day & Night Adjustable IRVM
Power & Tilt Steering
Electrically Adjustable ORVMs
Electrically Foldable ORVMs
Retractable ORVMs (Key Operated)
Bottle Holders (in each row)
Coin/Ticket Holder (Driver Side)
Cabin Lamp (Fr.+Rr.)
Cruise Control
Paddle Shifters		(AT)	(AT)	(AT)	(AT)	(AT)	(AT)	(AT)	(AT)
Foot Rest
Courtesy Lamp
Auto Headlamps with Follow Me Home/Lead me to Vehicle Feature

INFOTAINMENT SYSTEM

	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
17.78cm SmartPlay Pro Touch Screen Infotainment System
17.78cm SmartPlay Studio Touch Screen Infotainment System
Premium Sound System				ARKAMYS (Surround Sense)	ARKAMYS (Surround Sense)
Android Auto^*~ & Apple Car Play^~				Wireless	Wireless
Audio System with Electrostatic Touch Buttons
Bluetooth Connectivity
Speakers(4)
Tweeters(2)
USB and AUX Connectivity	USB Only	USB Only	USB Only	USB Only	USB Only
Steering Mounted Audio Control
Steering Mounted Calling Control
^*~ Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Maps™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link:https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc. Image used are for illustration purposes only.
^~ Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link:http://www/apple.com/ios/carplay

SAFETY & SECURITY

	LXi MT	VXi MT	VXi AT	VXi CNG	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
Suzuki HEARTECT Platform
6 Airbags (Front,Side and Curtain)
Tyre Pressure Monitoring System (TPMS)
ABS with EBD and Brake Assist
Engine Immobilizer
Electronic Stability Program
Hill Hold
ISOFIX Child Seat Anchorages (2nd Row Seats)
Front Seat Belts with Pre-tensioner & Force Limiters (Dr.+Co-Dr.)
Seat Belt Reminder Lamp and Buzzer (All Passengers)
All Seat Belts (3-Point ELR)
Front Seat Belt Height Adjuster
High Speed Alert System^{^}
Speed Sensitive Auto Door Lock
Security Alarm
Rear Parking Sensors
Rear Parking Camera
Central Locking
Front Fog Lamps
^{^} The speed alert system gives audible warning for alert of over-speed to driver. When vehicle speed exceeds about 80 km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.

**SUZUKI CONNECT

	Zxi MT	ZXi AT	ZXi CNG	ZXi+ MT	ZXi+ AT
Safety and Security
Emergency Alerts
Breakdown Notification
Stolen Vehicle Notification and Tracking
Tow Away Alert and Tracking
Geo-Fence
Time Fence
Valet Alert
Trips and Driving Behaviour
Trip Summary
Driving Behaviour
Share Trip History
Area Guidance Around Destination
Vehicle location Sharing
Alerts and Notifications
Overspeed
Seatbelt
AC Idling
Trip (Start & End)
Low Fuel^{^*} & Low Range^##
Dashboard View
Remote functions
Door Lock/Cancel Lock
Hazard Light ON/OFF
Headlight OFF^{^^*}
Alarm
Immobilizer Request
Battery Health
Smartwatch Connectivity
Suzuki Connect skill for Amazon, Alexa****
Remote Ac	(AT)	(AT)	(AT)	(AT)	(AT)
^Suzuki Connect (available through phone/smartwatch/Suzuki connect skill for Amazon Alexa).**
****Amazon, Alexa and all related marks are trademarks of Amazon.com, Inc. or its affiliates. This is to clarify that LXi (O), VXi (O) & ZXi (O) are same variants with same features as LXi , VXi & ZXi.

Dimensions
Engine
Drive & Transmission
Brake
Suspension
Weight

Dimension

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Length (mm)	4435	4435	4435	4435	4435	4435	4435	4435	4435
Width (mm)	1735	1735	1735	1735	1735	1735	1735	1735	1735
Height (mm)	1690	1690	1690	1690	1690	1690	1690	1690	1690
Wheelbase (mm)	2740	2740	2740	2740	2740	2740	2740	2740	2740
Turning Radius (m)	5.2	5.2	5.2	5.2	5.2	5.2	5.2	5.2	5.2
Seating Capacity	7	7	7	7	7	7	7	7	7

Engine

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Type	K15C SMART HYBRID	K15C SMART HYBRID	K15C SMART HYBRID	K15C	K15C SMART HYBRID	K15C SMART HYBRID	K15C	K15C SMART HYBRID	K15C SMART HYBRID
Capacity (cc)	1462	1462	1462	1462	1462	1462	1462	1462	1462
Compression Ratio	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3	12 ± 0.3
Power (KW@RPM)	75.8 KW(103.06 Ps) @ 6000 rpm	75.8 KW(103.06 Ps) @ 6000 rpm	75.8 KW(103.06 Ps) @ 6000 rpm	74.0 KW(100.06 Ps) @ 6000 rpm (Petrol Mode) 64.6KW(87.8 Ps) @ 5500 rpm (CNG Mode)	75.8 KW(103.06 Ps) @ 6000 rpm	75.8 KW(103.06 Ps) @ 6000 rpm	74.0 KW(100.06 Ps) @ 6000 rpm (Petrol Mode) 64.6 KW(87.8 Ps) @ 5500 rpm (CNG Mode)	75.8 KW(103.06 Ps) @ 6000 rpm	75.8 KW(103.06 Ps) @ 6000 rpm
Torque(Nm@RPM)	139.0 Nm @ 4300 rpm	139.0 Nm @ 4300 rpm	139.0 Nm @ 4300 rpm	137.1 Nm @ 4300 rpm (Petrol Mode) 121.5 Nm @ 4200 rpm (CNG Mode)	139.0 Nm @ 4300 rpm	139.0 Nm @ 4300 rpm	137.1 Nm @ 4300 rpm (Petrol Mode) 121.5 Nm @ 4200 rpm (CNG Mode)	139.0 Nm @ 4300 rpm	139.0 Nm @ 4300 rpm
Emission Type	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI
Fuel Tank Capacity (L)	45	45	45	Petrol:45 CNG: 60 (Water Equivalent)	45	45	Petrol:45 CNG: 60 (Water Equivalent)	45	45
Idle Start Shop
Brake Energy Regeneration
Torque Assist

Drive & Transmission

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Drive	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF	2WD,FF
Transmission	5MT/6AT	5MT/6AT	5MT/6AT	5MT	5MT/6AT	5MT/6AT	5MT	5MT/6AT	5MT/6AT

Break

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Suspension

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Front	MacPherson Strut & Coil Spring	MacPherson Strut & Coil Spring	MacPherson Strut & Coil Spring	MacPherson Strut & Coil Spring	MacPherson Strut & Coil Spring	MacPherson Strut & Coil Spring	MacPherson Strut & Coil Spring	MacPherson Strut & Coil Spring	MacPherson Strut & Coil Spring
Rear	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring
Tyre Size	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15	185/65 R15

Weight

	LXi MT	VXi MT	VXi AT	VXi MT CNG	Zxi MT	ZXi AT	ZXi MT CNG	ZXi+ MT	ZXi+ AT
Kerb Weight (kg)	1175-1225	1175-1225	1175-1225	1270-1275	1175-1225	1175-1225	1270-1275	1175-1225	1175-1225
Gross Vehicle Weight (kg)	1760(MT),1785(AT)	1760(MT),1785(AT)	1760(MT),1785(AT)	1820	1760(MT),1785(AT)	1760(MT),1785(AT)	1820	1760(MT),1785(AT)	1760(MT),1785(AT)

Swift

EXTERIORS
INTERIORS
SAFETY & SECURITY
AUDIO & ENTERTAINMENT
COMFORT & CONVENIENCE

Exteriors

	LXi 5MT	VXi 5MT/5AMT	VXi CNG 5MT	VXi (O) 5MT/5AMT	VXi (O) CNG 5MT	ZXi 5MT/5AMT	ZXi CNG 5MT	ZXi+ 5MT/5AMT
Projector Headlamps	(Halogen)	(Halogen)	(Halogen)	(Halogen)	(Halogen)	(LED)	(LED)	(LED)
LED Daylight Running Lamps
LED Rear Combination Lamps
Wheels (Steel/Alloy/Precision Cut Alloy)	Steel	Steel	Steel	Steel	Steel	Painted Alloy	Painted Alloy	Precision Cut Alloy
Full Wheel Covers
Side Turn Indicators on ORVMs
Body Coloured Outside Rear View Mirrors
Body Coloured Bumpers
Body Coloured Outside Door Handles
Roof Antenna (Micropole)
Front LED Fog Lamps

INTERIORS

	LXi 5MT	VXi 5MT/5AMT	VXi CNG 5MT	VXi (O) 5MT/5AMT	VXi (O) CNG 5MT	ZXi 5MT/5AMT	ZXi CNG 5MT	ZXi+ 5MT/5AMT
Leather Wrapped Steering Wheel (With Stitch)⁴
Outside Temperature Display		(AMT)	(AMT)	(AMT)	(AMT)
Co-driver Side Sunvisor with Vanity Mirror
Driver Side Sunvisor with Ticket Holder
Chrome Parking Brake Lever Tip
Gear Shift Knob in Piano Black Finish
Tachometer
Multi-information Display	(Segment)	(Segment)	(Segment)	(Segment)	(Segment)	(Segment)	(Segment)	(Coloured)
Front Footwell Illumination
Rear Parcel Tray
Front & Rear Bottle Holder
Luggage Room Lamp
⁴Certain parts of leather upholstery contains man-made materials.

SAFETY & SECURITY

	VXi 5MT/5AMT	VXi CNG 5MT	VXi (O) 5MT/5AMT	VXi (O) CNG 5MT	ZXi 5MT/5AMT	ZXi CNG 5MT	ZXi+ 5MT/5AMT
Side and Curtain Airbags⁵
Dual Front Airbags (Driver & Co-driver)⁵
ABS with EBD
Electronic Stability Program
Hill Hold Assist
Reverse Parking Sensors
Wide-angle Rear Parking Camera
Security Alarm System - Door & Hood							(Incl. Shock Sensor)
Front Seatbelts with Pretensioner and Force Limiter
ISOFIX with Child Seat Anchorages
Speed Sensitive Automatic Door Lock
Seatbelt Reminder with Buzzer (Front + Rear Seat)⁶
Day and Night Adjustable Inside Rear View Mirror	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)
Engine Immobilizer
High Speed Alert System⁷
Driver Seat Height Adjuster
Warning Lamp/Reminder for Low Fuel, Door Ajar
⁵For details on functioning of safety features, including airbags, kindly refer to the Owner's Manual.
⁶Seatbelt reminder comes on unless all rear passenger's seatbelts are fastened irrespective of the presence or absence of passenger.
⁷The speed alert system gives audible warning for alert of overspeeding to driver. When vehicle speed exceeds about 80 km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.

AUDIO & ENTERTAINMENT

	LXi 5MT	VXi 5MT/5AMT	VXi CNG 5MT	VXi (O) 5MT/5AMT	VXi (O) CNG 5MT	ZXi 5MT/5AMT	ZXi CNG 5MT	ZXi+ 5MT/5AMT
SmartPlay Pro+ with 22.86 cm Touch Screen
SmartPlay Pro with 17.78 cm Touch Screen
Surround Sense Powered by ARKAMYS
Onboard Voice Assistant (Wake-up through "Hi Suzuki" with Barge-in Feature)
Over the Air (OTA) System Upgrades using Smartphones
Wireless Android Auto & Apple CarPlay⁸
Steering Mounted Audio & Calling Controls
FM/AM, USB, Bluetooth Connectivity
Speakers (4)
Tweeters (2)
⁸Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link:http://www.apple.com/ios/feature-availability/ #applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link: http://www/apple.com/ios/carplay. Android Auto™ extends the Android platform into the car in a way that’s purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Maps™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link: https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto:https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc.

COMFORT & CONVENIENCE

	LXi 5MT	VXi 5MT/5AMT	VXi CNG 5MT	VXi (O) 5MT/5AMT	VXi (O) CNG 5MT	ZXi 5MT/5AMT	ZXi CNG 5MT	ZXi+ 5MT/5AMT
Cruise Control
Wireless Charger
Engine Push Start-Stop Button with Smart Key
Rear Wiper & Washer
Auto Headlamps (Lead Me to Vehicle, Follow Me Home)
Digital Air Conditioner with Panel Illumination	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Auto)	(Auto)	(Auto)
Rear AC Vents
Keyless Entry System
Central Door Locking
Auto Up/Down Power Window with Anti-pinch (Driver Side)
Power Windows (Front + Rear)
Power & Tilt Steering
Manually Adjustable Outside Rear View Mirrors
Electrically Adjustable Outside Rear View Mirrors
Electrically Foldable Outside Rear View Mirrors								(Auto)
Electric Back Door Opener
Rear Defogger
Adjustable Front Seat Headrests
Adjustable Rear Seat Headrests
Gear Position Indicator		(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)	(AMT only)
Gear Shift Indicator		(MT only)	(MT only)	(MT only)	(MT only)	(MT only)	(MT only)	(MT only)
Driver Side Foot Rest
60:40 Split Rear Seat
Front Accessory Socket
Front USB Ports (Type A)
Rear USB Ports (Type A & C)
Tyre Repair Kit		CNG Only	CNG Only	CNG Only	CNG Only	CNG Only	CNG Only

DIMENSIONS
ENGINE
TRANSMISSION TYPE
WEIGHT
EMISSION TYPE
BRAKE
SUSPENSION
WHEEL & TYRE SIZE³

Dimensions

	LXi 5MT	VXi 5MT/5AMT	VXi (O) 5MT/5AMT	ZXi 5MT/5AMT	ZXi+ 5MT/5AMT	VXi CNG 5MT	VXi (O) CNG 5MT	ZXi CNG 5MT
Total Length (mm)	3860	3860	3860	3860	3860	3860	3860	3860
Total Width (mm)	1735	1735	1735	1735	1735	1735	1735	1735
Total Height (mm) (Unladen)	1520	1520	1520	1520	1520	1520	1520	1520
Wheel Base (mm)	2450	2450	2450	2450	2450	2450	2450	2450
Min. Turning Radius (m)	4.8	4.8	4.8	4.8	4.8	4.8	4.8	4.8
Ground Clearance (mm) (Unladen)	163	163	163	163	163	163	163	163
Fuel Tank Capacity (L)	37	37	37	37	37	Petrol: 37; CNG: 55 (Water Filling Capacity)	Petrol: 37; CNG: 55 (Water Filling Capacity)	Petrol: 37; CNG: 55 (Water Filling Capacity)
Boot Space (L)¹	265	265	265	265	265
Seating Capacity	5	5	5	5	5	5	5	5
^¹VDA Method

ENGINE

	LXi 5MT	VXi 5MT/5AMT	VXi (O) 5MT/5AMT	ZXi 5MT/5AMT	ZXi+ 5MT/5AMT	VXi CNG 5MT	VXi (O) CNG 5MT	ZXi CNG 5MT
Engine Type	Z12E with ISS	Z12E with ISS	Z12E with ISS	Z12E with ISS	Z12E with ISS	Z12E without ISS	Z12E without ISS	Z12E without ISS
Fuel Type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol+CNG	Petrol+CNG	Petrol+CNG
Engine Capacity (cc)	1197	1197	1197	1197	1197	1197	1197	1197
Max. Power	60 kW @ 5700 rpm or 81.58 PS @ 5700 rpm	60 kW @ 5700 rpm or 81.58 PS @ 5700 rpm	60 kW @ 5700 rpm or 81.58 PS @ 5700 rpm	60 kW @ 5700 rpm or 81.58 PS @ 5700 rpm	60 kW @ 5700 rpm or 81.58 PS @ 5700 rpm	51.3 kW @ 5700rpm or 69.75PS@5700rpm	51.3 kW @ 5700rpm or 69.75PS@5700rpm	51.3 kW @ 5700rpm or 69.75PS@5700rpm
Max. Torque	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	111.7 Nm @ 4300 rpm	101.8 Nm @ 2900 rpm	101.8 Nm @ 2900 rpm	101.8 Nm @ 2900 rpm
Number of Cylinders	3	3	3	3	3	3	3	3
Fuel Efficiency^²	24.8 km/l (MT) & 25.75 km/l (AMT)	24.8 km/l (MT) & 25.75 km/l (AMT)	24.8 km/l (MT) & 25.75 km/l (AMT)	24.8 km/l (MT) & 25.75 km/l (AMT)	24.8 km/l (MT) & 25.75 km/l (AMT)	32.85 km/kg (MT)	32.85 km/kg (MT)	32.85 km/kg (MT)
Idle Start Stop
^² Fuel efficiency as certified by test agency under Rule 115 of CMVR 1989.

TRANSMISSION TYPE

	LXi 5MT	VXi 5MT/5AMT	VXi (O) 5MT/5AMT	ZXi 5MT/5AMT	ZXi+ 5MT/5AMT	VXi CNG 5MT	VXi (O) CNG 5MT	ZXi CNG 5MT
Manual	5MT	5MT	5MT	5MT	5MT	5MT	5MT	5MT
Automatic	5AMT	5AMT	5AMT	5AMT	5AMT	5AMT	5AMT	5AMT

WEIGHT

	LXi 5MT	VXi 5MT/5AMT	VXi (O) 5MT/5AMT	ZXi 5MT/5AMT	ZXi+ 5MT/5AMT	VXi CNG 5MT	VXi (O) CNG 5MT	ZXi CNG 5MT
Vehicle Kerb Weight (kg)	920 max (MT), 925 max (AMT)	920 max (MT), 925 max (AMT)	920 max (MT), 925 max (AMT)	920 max (MT), 925 max (AMT)	920 max (MT), 925 max (AMT)	990 max (MT)	990 max (MT)	990 max (MT)
Gross Vehicle Weight (kg)	1355	1355	1355	1355	1355	1425	1425	1425

EMISSION TYPE

	LXi 5MT	VXi 5MT/5AMT	VXi (O) 5MT/5AMT	ZXi 5MT/5AMT	ZXi+ 5MT/5AMT	VXi CNG 5MT	VXi (O) CNG 5MT	ZXi CNG 5MT
Bharat Stage Wise	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI

BRAKE

	LXi 5MT	VXi 5MT/5AMT	VXi (O) 5MT/5AMT	ZXi 5MT/5AMT	ZXi+ 5MT/5AMT	VXi CNG 5MT	VXi (O) CNG 5MT	ZXi CNG 5MT
Front Brakes	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc
Rear Brakes	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

SUSPENSION

	LXi 5MT	VXi 5MT/5AMT	VXi (O) 5MT/5AMT	ZXi 5MT/5AMT	ZXi+ 5MT/5AMT	VXi CNG 5MT	VXi (O) CNG 5MT	ZXi CNG 5MT
Front Suspension	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut
Rear Suspension	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam	Torsion Beam

WHEEL & TYRE SIZE^³

	LXi 5MT	VXi 5MT/5AMT	VXi (O) 5MT/5AMT	ZXi 5MT/5AMT	ZXi+ 5MT/5AMT	VXi CNG 5MT	VXi (O) CNG 5MT	ZXi CNG 5MT
Tyre Size	165/80 R14 (LXi, VXi, VXi (O) ), 185/65 R15 (ZXi, ZXi+)	165/80 R14 (LXi, VXi, VXi (O) ), 185/65 R15 (ZXi, ZXi+)	165/80 R14 (LXi, VXi, VXi (O) ), 185/65 R15 (ZXi, ZXi+)	165/80 R14 (LXi, VXi, VXi (O) ), 185/65 R15 (ZXi, ZXi+)	165/80 R14 (LXi, VXi, VXi (O) ), 185/65 R15 (ZXi, ZXi+)	165/80 R14 (LXi, VXi, VXi (O) ), 185/65 R15 (ZXi, ZXi+)	165/80 R14 (LXi, VXi, VXi (O) ), 185/65 R15 (ZXi, ZXi+)	1165/80 R14 (LXi, VXi, VXi (O) ), 185/65 R15 (ZXi, ZXi+)
^³For Gasoline variants, spare tyre wheel material is steel & spare tyre is 165/80 R14.

S-Presso

Interiors
Comfort
Infotainment System
Safety and Security
Exterior
Instrument Cluster

Interiors

	VXi+ MT	VXi+(O) AGS
Dynamic Centre Console
High Seating for commanding drive view
Coloured Centre Garnish	**	**
Front Cabin Lamp (3 positions)
Sunvisor (Dr+Co. Dr)
**Orange in solid sizzle orange body colour & Silver in the remaining 5 body colours.

Comfort

	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT
AC with Heater
Power Steering
Accessory Socket
Front Console Utility Space
1L Bottle Holders with Map Pockets (Front doors)
Rear Console Utility Space
Co-Driver Side Utility Space
Reclining & Front Sliding Seats
Remote keyless entry
Rear Parcel Tray
Front Power Windows
Internally Adjustable ORVMs (Dr+Co. Dr)
Electrically Adjustable ORVMs (Dr+Co. Dr)
Idle Start Stop (ISS)	Petrol Variant Only	Petrol Variant Only	Petrol Variant Only	Petrol Variant Only	Petrol Variant Only

Infotainment System

	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
SmartPlay Studio - 17.78 cm Touch screen Infotainment System
SmartPlay Dock
Apple Car Play and Android Auto^###
Bluetooth
Speakers	2	2	2	2	2
USB connectivity/Aux
Steering-Mounted Audio & Voice Control
HEARTECT Platform
###Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link: http://www/apple.com/ios/carplay. Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Map™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link: https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc.

Safety and Security

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Cabin Air Filter
ESP with Hill Hold				AGS Only	AGS Only	AGS Only	AGS Only	AGS Only
ABS with EBD
Seat Belt Reminder with Buzzer Front + Rear seat^{^^}
Rear Seat Belt Center (2-Point Static)		Petrol variant only	Petrol variant only	Petrol variant only	Petrol variant only	Petrol variant only
Rear Seat Belt Outboard (3-Point)	(Static)	(Static)	(Static)	(ELR)	(ELR)	(ELR)	(ELR)	(ELR)
Reverse Parking Sensors
Speed Alert System^{^}
Pedestrian Protection
Child Proof Rear Door Lock
Speed Sensitive Auto Door Lock
Central Door Locking
Dual Airbag^#
Front Seatbelt Pre-tensioner and Force Limiter
Low Fuel Warning (Petrol Fuel)				SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Door Ajar Warning				SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Parking Brake Warning
^^Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^The speed alert system gives audible warning for alert of over-speed to driver. When the vehicle speed exceeds about 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118km/h, primary warning will resume. If the vehicle is slowed down to 78km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
#For details on the functioning of safety features including airbags, kindly refer to the Owners Manual.

Exterior

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
SUV Inspired Bold Front Fascia
Twin Chamber Headlamps
Roof Antenna
Signature C shaped Tail Lamps
B-Pillar Black Out Tape
Side Body Cladding
Body Coloured Bumpers
Body Coloured ORVMs
Body Coloured Outside Door Handles
Full Wheel Covers

Instrument Cluster

	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Digital Display in the Instrument Cluster
Fuel Consumption (Instantaneous & Average)
Headlamp On Warning
Gear Shift Indicator (MT Only)	Petrol Variant Only	Petrol Variant Only	Petrol Variant Only
Gear Position Indicator	AGS Only	AGS Only	AGS Only	AGS Only	AGS Only
Distance to empty

Dimensions
Engine
Emission Type
Drive & Transmission
Brake
Suspension
Weight

Dimensions

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Length (mm)	3565	3565	3565	3565	3565	3565	3565	3565
Width (mm)	1520	1520	1520	1520	1520	1520	1520	1520
Height (mm)	1553	1553	1553	1567	1567	1567	1567	1567
Wheelbase (mm)	2380	2380	2380	2380	2380	2380	2380	2380
Turning Radius (m)	4.5	4.5	4.5	4.5	4.5	4.5	4.5	4.5
Seating Capacity	5	5	4	5	5	4	5	5

Engine

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Type	K10C	K10C	K1OC CNG	K10C	K10C	K1OC CNG	K10C	K10C
Capacity (cc)	998	998	998	998	998	998	998	998
Power	49 kW(66.621PS) @ 5500 rpm	49 kW(66.621PS) @ 5500 rpm	41.7 kW (56.696PS) @ 5300 rpm (CNG Mode) 48 kW (65.261PS) @ 5500 rpm (Petrol Mode)	49 kW(66.621PS) @ 5500 rpm	49 kW(66.621PS) @ 5500 rpm	41.7 kW (56.696PS) @ 5300 rpm (CNG Mode) 48 kW (65.261PS) @ 5500 rpm (Petrol Mode)	49 kW(66.621PS) @ 5500 rpm	49 kW(66.621PS) @ 5500 rpm
Torque	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG Mode) 89 Nm @ 3500 rpm (Petrol Mode)	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG Mode) 89 Nm @ 3500 rpm (Petrol Mode)	89 Nm @ 3500 rpm	89 Nm @ 3500 rpm
Fuel Type	Petrol	Petrol	Petrol+CNG	Petrol	Petrol	Petrol+CNG	Petrol	Petrol
Fuel Tank Capacity (L)	27	27	27 (Petrol Mode) 55 (CNG Mode) (Equivalent Water Filling Capacity)	27	27	27 (Petrol Mode) 55 (CNG Mode) (Equivalent Water Filling Capacity)	27	27

Emission Type

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Type	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI

Drive & Transmission

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Drive	2WD, FF	2WD, FF	2WD, FF	2WD, FF	2WD, FF	2WD, FF	2WD, FF	2WD, FF
Transmission	5MT/ AGS	5MT/ AGS	5MT	5MT/ AGS	5MT/ AGS	5MT	5MT/ AGS	5MT/ AGS

Brake

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Front	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Suspension

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Front	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring and Stabilizer Bar	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring and Stabilizer Bar	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring
Tyre Size	145/80 R13	145/80 R13	145/80 R13	165/70 R14	165/70 R14	165/70 R14	165/70 R14	165/70 R14

Weight

	Std MT	LXi MT	LXi CNG MT	VXi MT	VXi(O) AGS	VXi CNG MT	VXi+ MT	VXi+(O) AGS
Kerb Weight (kg)	736-775	736-775	834-854	736-775	736-775	834-854	736-775	736-775
Maximum GVW (kg)	1170	1170	1170	1170	1170	1170	1170	1170

Brezza

Exteriors
Interiors
Safety
INFOTAINMENT
Comfort & Convenience
Colour Variants

Exteriors

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Auto Headlamps with Follow me Home & Lead Me to Vehicle
Alloy Wheels						(Painted)	(Painted)	(Painted)	(Precision Cut)	(Precision Cut)
Steel Wheels with Wheel cover
Projector Headlamps	(Bi-Halogen)	(Bi-Halogen)	(Bi-Halogen)	(Bi-Halogen)	(Bi-Halogen)	(Dual LED)	(Dual LED)	(Dual LED)	(Dual LED)	(Dual LED)
Floating LED Day Time Running Lamps
Front Fog Lamps (LED)
Roof Rail
Roof End Spoiler
Chrome Accentuated Front Grille
Rear Combination Lamp (LED)
Shark Fin Antenna
Dual Tone Exterior (In Selected Colours)
Wheel Arch Cladding
Skid Plate (Fr & Rr)	(Black)	(Black)	(Black)	(Black)	(Black)	(Silver)	(Silver)	(Silver)	(Silver)	(Silver)
Side Under Body Cladding
Side Door Cladding

Interiors

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Interior Color Theme	(Mono Tone)	(Mono Tone)	(Mono Tone)	(Mono Tone)	(Mono Tone)	(Dual Tone)	(Dual Tone)	(Dual Tone)	(Dual Tone)	(Dual Tone)
Interior Ambient Lights
Leather Wrapped Steering Wheel^
Co-Driver Side Vanity Lamp
Chrome Plated Inside Door Handles
Door Armrest With Fabric
Luggage Lamp
Glove Box Illumination
Front Footwell Illumination
Cabin Lamp
Flat Bottom Steering Wheel
Rear Parcel Tray
Hook In Luggage Area
IP Ornament	(Black)	(Black)	(Black)	(Black)	(Black)	(Silver)	(Silver)	(Silver)	(Silver)	(Silver)
^Some parts of the leather appointed upholstery will contain man-made material.

Safety

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Head up Display
360 View Camera
Side and Curtain Airbags^^
Shoulder Height Adjustable Front Seat Belts
Electronic Stability Program (ESP)
Hill Hold Assist
Driver & Co-Driver Airbags^^
Rear View Camera
Front Seat Belt Pre-tensioners & Force Limiter
Reverse Parking Sensor with Infographic Display
High Speed Warning Alert#
Seat Belt Reminder Lamp & Buzzer (Driver & Co-Driver)
Rear Wiper & Washer
Rear Defogger (Electric)
Anti-theft Security System
Suzuki TECT Body
Dual Horn
Engine Immobilizer
ISOFIX Child Seat Restraint System
Impact Sensing Door Unlock
Day/Night Rear View Mirror	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Manual)	(Auto)	(Auto)
Door Ajar Warning Lamp
Central Locking	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)	(5 Door)
^^For details on functioning of safety features including air bag, kindly refer to the Owners Manual.
#If the vehicle’s speed exceeds 80 km/h, then the primary level warning will beep twice every minute. And if the vehicle speed goes above 120 km/h, the secondary level warning will keep beeping. If the vehicle speed slows down to 118 km/h, primary warning will resume. If the vehicle is slowed down to 78 km/h, speed alert warning will stop. This buzzer does not include any malfunction in the vehicle.

INFOTAINMENT

	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Touch Screen Audio	17.78cm (SmartPlay Studio)	17.78cm (SmartPlay Studio)	17.78cm (SmartPlay Studio)	17.78cm (SmartPlay Pro)	17.78cm (SmartPlay Pro)	17.78cm (SmartPlay Pro)	22.86cm (SmartPlay Pro+)	22.86cm (SmartPlay Pro+)
Premium Sound System				ARKAMYS	ARKAMYS	ARKAMYS	ARKAMYS (Surround Sense)	ARKAMYS (Surround Sense)
Android Auto and Apple CarPlay###				Wireless	Wireless	Wireless	Wireless	Wireless
Remote Control App for Infotainment
Steering Mounted Controls: Audio and Bluetooth
Over the Air Update (OTA)
Onboard Voice Assistant (Wake up through Hi Suzuki with Barge in Feature)
USB & Bluetooth Connectivity
Speakers (4)
Tweeters (2)
MID with TFT Color Display
MID with Segment Display
Speedometer with Tachometer
Audible Headlight On Reminder
Low Fuel Warning Light
Gear Shift Indicator (MT Only)
###Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link: http://www/apple.com/ios/carplay. Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Map™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link: https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc.

Comfort & Convenience

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Electric Sunroof
Wireless Charging Dock
Rear Fast Charging USB (Type A and C)
Cruise Control
Height Adjustable Driver Seat
Front Center Armrest (Sliding Type With Storage)
Cooled Glove Box
60:40 Split Seat (Rear)
Overhead Console with Sunglass Holder & Map Lamp
Engine Push Start/stop With Smart Key
Rear Center Armrest With Cup Holder
Adjustable Rear Seat Headrest
Electrically Adjustable ORVM
Electrically Foldable ORVM									(Auto Fold)	(Auto Fold)
Driver Side Front Window (Auto Up/Down)
Rear AC Vents
Auto Climate control
Keyless Entry System
Front & Rear Power Windows
Steering Column Adjustment	(Tilt)	(Tilt)	(Tilt)	(Tilt)	(Tilt)	(Tilt & Telescopic)	(Tilt & Telescopic)	(Tilt & Telescopic)	(Tilt & Telescopic)	(Tilt & Telescopic)
Front Accessory Socket

Colour Variants

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Splendid Silver With Midnight Black Roof (Dual Tone)
Sizzling Red with Midnight Black Roof (Dual Tone)
Brave Khakhi with Arctic White Roof (Dual Tone)
Brave Khakhi
Splendid Silver
Sizzling Red
Exuberant Blue
Pearl Arctic White
Magma Grey

Engine
DIMENSIONS
Transmission
Brakes
Suspension
Tyre

Engine

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Engine Type	K15C Smart Hybrid	K15C	K15C Smart Hybrid	K15C Smart Hybrid	K15C	K15C Smart Hybrid	K15C Smart Hybrid	K15C	K15C Smart Hybrid	K15C Smart Hybrid
Fuel Type	Petrol Mode	CNG Mode	Petrol Mode	Petrol Mode	CNG Mode	Petrol Mode	Petrol Mode	CNG Mode	Petrol Mode	Petrol Mode
Capacity (cc)	1462	1462	1462	1462	1462	1462	1462	1462	1462	1462
Max Power (kW @ RPM)	75.8 @ 6000	74.0 @ 6000 (Gasoline) 64.6 kW @ 5500	75.8 @ 6000	75.8 @ 6000	74.0 @ 6000 (Gasoline) 64.6 kW @ 5500	75.8 @ 6000	75.8 @ 6000	74.0 @ 6000 (Gasoline) 64.6 kW @ 5500	75.8 @ 6000	75.8 @ 6000
Max Torque (Nm @ RPM)	136.8 @ 4400	136.0 @ 4400 (Gasoline) 121.5 Nm @ 4200	136.8 @ 4400	136.8 @ 4400	136.0 @ 4400 (Gasoline) 121.5 Nm @ 4200	136.8 @ 4400	136.8 @ 4400	136.0 @ 4400 (Gasoline) 121.5 Nm @ 4200	136.8 @ 4400	136.8 @ 4400
Emission Type	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI	BS VI
Fuel Efficiency	20.15 km/l	25.51 km/kg	20.15 km/l	19.80 km/l	25.51 km/kg	19.89 km/l	19.80 km/l	25.51 km/kg	19.89 km/l	19.80 km/l
Fuel Tank Capacity (L)	48	Petrol: 48 CNG: 55 (Water Equivalent)	48	48	Petrol: 48 CNG: 55 (Water Equivalent)	48	48	Petrol: 48 CNG: 55 (Water Equivalent)	48	48
Idle Start Stop
Brake Energy Regeneration
Torque Assist During Acceleration

Dimensions

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Length(mm)	3995	3995	3995	3995	3995	3995	3995	3995	3995	3995
Width(mm)	1790	1790	1790	1790	1790	1790	1790	1790	1790	1790
Height (unladen) (mm)	1685	1685	1685	1685	1685	1685	1685	1685	1685	1685
Wheelbase (mm)	2500	2500	2500	2500	2500	2500	2500	2500	2500	2500
Seating capacity	5	5	5	5	5	5	5	5	5	5
Boot Space (L)	328*		328*	328*		328*	328*		328*	328*
*VDA Method.

Transmission

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Transmision	5 MT / 6AT	5 MT	5 MT / 6AT	5 MT / 6AT	5 MT	5 MT / 6AT	5 MT / 6AT	5 MT	5 MT / 6AT	5 MT / 6AT

Brakes

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Front	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Suspension

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Front	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil	Mac Pherson Strut & Coil
Rear	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring	Torsion Beam & Coil Spring

Tyre

	LXI MT	LXI CNG MT	VXI MT	VXI AT	VXI CNG MT	ZXI MT	ZXI AT	ZXI CNG MT	ZXI+ MT	ZXI+ AT
Tyre Size	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##	215/60 R16##
##Spare wheel material is steel & spare tyre size is 215/60 R16.

WagonR

Interiors
Instrument Cluster
Comfort and Convenience
Infotainment System
Safety and Security
Exteriors

Interiors

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Dual Tone Interiors
2^nd Row 60:40 Split Seat
Front Cabin Lamps (3 Positions)
Day/Night IRVM
Tilt Steering
Steering Wheel Garnish
Silver Inside Door Handles
Driver Side Sunvisor with Ticket Holder
Front Passenger Side Vanity Mirror Sunvisor
Silver Finish Gear Shift Knob (AGS only)

Instrument Cluster

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Instrument Cluster Meter Theme	Reddish Amber	Reddish Amber	Reddish Amber	Reddish Amber	Reddish Amber	Reddish Amber	Reddish Amber	White	White
Low Fuel Warning
Tachometer
Gear Shift Indicator (MT Only)
Gear Position Indicator (AGS Only)
Fuel Consumption (Instantaneous and Average)
Distance to empty
Headlamp On Warning
Door Ajar Warning Lamp

Comfort and Convenience

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L
Idle Start Stop(ISS)	(Petrol)	(Petrol)	(Petrol)	(Petrol)	(Petrol)
Remote Keyless Entry
Accessory Socket Front Row with Storage Space
Power Windows (Fr/Rr) with Dr. Slide Auto Down Function	Only Front	Only Front
AC & Heater
1L Bottle Holders (All Four Doors + Floor Console)
Rear Parcel Tray	CNG Only	CNG Only
Co. Driver Side Front Seat Under Tray and Rear Back Pocket
Reclining & Front Sliding Seats

Infotainment System

	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
17.78 cm Smartplay Studio with Smartphone Navigation
Smartplay Dock
Apple Carplay and Android Auto
Bluetooth
Number of Speakers	2	2	2	2	2	4	4
USB Connectivity/AUX
Steering Mounted Audio Control
Steering Mounted Voice Control

Safety And Security

	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Driver Airbag^##
Passenger Airbag
ABS with EBD
Electronic Stability Program (ESP)
Seat Belt Pre-tensioner and Force Limiters (Dr.+Co-Dr.)
Seat Belt Reminder with Buzzer (Front & Rear Seat)^{^^#}
Seat Belts for all seats^{^^^}
Speed Alert System^{^^}
Speed Sensitive Auto Door Lock
Security Alarm
Rear Parking Sensors
Central Locking
Child Proof Rear Door Lock
Front Fog Lamps
Hill Hold Assist	AGS	AGS	AGS	AGS	AGS	AGS	AGS
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
^^#Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^^^Rear Centre seat has lap belt type of seat belt.
^^The speed alert system gives audible warning for alert of over-speed to driver. When the vehicle speed exceeds about 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118km/h, primary warning will resume. If the vehicle is slowed down to 78km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.

Exteriors

	LXI 1.0L	LXI CNG 1.0L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Roof Antenna
Full Wheel Cover	(Center Cap)	(Center Cap)
Alloy Wheels
ORVM with Turn Indicators
Electrical Adjustable ORVM
Electrical Retractable ORVM
Rear Wiper and Washer
B-Pillar Black Out Tape
Body Coloured Door Handles
Body Coloured Bumpers
Body Coloured ORVMs			(Black In Dual tone)	(Black in Dual Tone)
Dual Tone Exteriors			(Optional)	(Optional)

Dimensions
Engine & Transmission
Suspension
Capacities
Wheels and Tyres
Brakes
Weight

DIMENSIONS

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Length (mm)	3655	3655	3655	3655	3655	3655	3655	3655	3655
Width (mm)	1620	1620	1620	1620	1620	1620	1620	1620	1620
Height (mm)	1675	1675	1675	1675	1675	1675	1675	1675	1675
Wheelbase (mm)	2435	2435	2435	2435	2435	2435	2435	2435	2435
Turning Radius (m)	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7

Engine & Transmission

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Type	K10C	K10C	K10C	K10C	K10C	K12N	K12N	K12N	K12N
Capacity (cc)	998	998	998	998	998	1197	1197	1197	1197
Number of Cylinders	3	3	3	3	3	4	4	4	4
Maximum engine output(kW @ rpm)	49.0 kW (66.62 PS) @ 5500 rpm	41.7 kW (56.70 PS) @ 5300 rpm (CNG mode) 48.0 kW (65.26 PS) @ 5500 rpm (Petrol mode)	49.0 kW (66.62 PS) @ 5500 rpm	49.0 kW (66.62 PS) @ 5500 rpm	41.7 kW (56.70 PS) @ 5300 rpm (CNG mode) 48.0 kW (65.26 PS) @ 5500 rpm (Petrol mode)	66 kW (89.73 PS) @ 6000 rpm	66 kW (89.73 PS) @ 6000 rpm	66 kW (89.73 PS) @ 6000 rpm	66 kW (89.73 PS) @ 6000 rpm
Maximum torque (Nm @ rpm)	89.0 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG mode) 89.0 Nm @ 3500 rpm (Petrol mode)	89.0 Nm @ 3500 rpm	89.0 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG mode) 89.0 Nm @ 3500 rpm (Petrol mode)	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm	113 Nm @ 4400 rpm
Transmission	MT	MT	MT	AGS	MT	MT/AGS	AGS	MT/AGS	AGS

Suspension

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Front	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring	MacPherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring

Capacities

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Seating Capacity	5	5	5	5	5	5	5	5	5
Fuel Tank Capacity (L)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)/ 60 (Water equivalent)	32 (Petrol)	32 (Petrol)	32 (Petrol)	32 (Petrol)
Boot Space (Litres)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)	341^ (Petrol)
^VDA Method.

Wheels and Tyres

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Size	155/80R13	155/80R13	165/70R14	165/70R14	165/70R14	165/70R14	165/70R14	165/70R14	165/70R14
Type**	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Steel Wheels	Radial & Tubeless, Alloy Wheels	Radial & Tubeless, Alloy Wheels
**Spare Wheel Material is steel(for all variants).

Brakes

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Front	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc	Disc
Rear	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum	Drum

Weight

	LXI 1.0L	LXI CNG 1.0L	VXI 1.0L	VXI AGS 1.0L	VXI CNG 1.0L	ZXI 1.2L	ZXI AGS 1.2L	ZXI+ 1.2L	ZXI+ AGS 1.2L
Gross Vehicle Weight (kg)	1340	1340	1340	1340	1340	1340	1340	1340	1340
Kerb Weight (kg)	810	910	825	835	920	835	840	845	850

Alto K10

Ex-showroom Price

Mileage

Petrol - 24.39 km/l* CNG - 33.85 km/kg#

*For Petrol Variants only. #In CNG mode CNG variants only. As certified by Test Agency Under Rule 115 (G) of CMVR 1989

download brochure

Features
Technical Specifications

Safety
Infotainment
Comfort & Convenience
Exteriors
Interiors

Safety

	STD MT	LXI MT	LXI CNG	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Rear Door Child lock
Engine Immobiliser
Speed Sensing Auto Door Lock
Central Door Locking
Impact Sensing Door Unlock
High Speed Alert^{^}
Front Seat Belts Pre-Tensioner & Force Limiter
Rear Seat Belt Center(2-Point Static)		(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)
Rear Seat Belt Outboard(3-Point)	(Static)	(Static)	(Static)	(ELR)	(ELR)	(ELR)	(ELR)	(ELR)
Dual Front Airbags^##
ABS with EBD
Reverse Parking Sensor
Seat Belt Reminder with Buzzer (Front & Rear Seat)
HEARTECT Platform
Headlamp Levelling
High-Mounted Stop Lamp
Collapsible Steering Column
^The speed warning for alert of over-speed to driver. When vehicle speed exceeds about 80 km/h primary level warning with two beeps will sound every minute. When the vehicle speed exces level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume if the vehicle is slowed down to about 28 km This buzzer does not indicate any malfunction in vehicle.
##For details on functioning of safety features, including airbag, kindly refer to the owner's manual

Infotainment

	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Touch Screen Audio				17.78 cm (SmartPlay Studio)	17.78 cm (SmartPlay Studio)
Media Receiver (AM/FM/Bluetooth)	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
AUX Port
USB Port
Remote Application
Bluetooth
Android Auto
Apple Carplay
Speakers	2	2	2	4	4
Steering Mounted Audio & Voice Control
Digital Speedometer
Distance to Empty	^{*^}	^{*^}	^{*^}
Fuel Consumption - Average	^{*^}	^{*^}	^{*^}
Fuel Consumption - Instantaneous	^{*^}	^{*^}	^{*^}
Gear Shift Indicator (MT only)	(Petrol Variant Only)	(Petrol Variant Only)	(Petrol Variant Only)
Gear Position Indicator (AGS only)
Low Fuel Warning	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Door Ajar Warning	SmartPlay Dock	SmartPlay Dock	SmartPlay Dock	SmartPlay Studio	SmartPlay Studio
Key off/Head lamp on Reminder
*^For VXI CNG variant, fuel consumption related data available only in Petrol Mode.
*^Availble only in VXi/VXi+variants as a limited edition till stock lasts.

Comfort & Convenience

	STD MT	LXI MT	LXI CNG	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Cabin Air Filter
Front Power Windows
Internally Adjustable ORVMs
Remote Keyless Entry
Remote Back Door Opener
Remote Fuel Lid Opener
Accessory Socket
Air Conditioner with Heater
Power Steering

Exteriors

	STD MT	LXI MT	LXI CNG	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Roof Antenna
Body Coloured Bumpers
Body Coloured Outside Door Handles
Wheel Covers	Center Cap	Center Cap	Center Cap	Full	Full	Full	Full	Full

Interiors

	STD MT	LXI MT	LXI CNG	VXI MT	VXI AGS	VXI CNG	VXI+ MT	VXI+ AGS
Sun Visor	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr	Dr.+Co Dr
Rear Parcel Tray
Assist Grips	Co- Dr.	Co- Dr.	Co- Dr.	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear	Co- Dr. + Rear
Front console utility space
1L Bottle Holder in Front doors with Map Pockets
Silver Accent Inside Door Handles
Silver Accent on Steering Wheel
Silver Accent on Side Louvers
Silver Accent on Center Garnish

Dimensions
Engine
Transmission
Suspension
Tyre
Brakes

Dimensions

	PETROL	CNG
Overall Length (mm)	3530	3530
Overall Width (mm)	1490	1490
Overall Height (Unladen) (mm)	1520	1520
Wheelbase(mm)	2380	2380
Turning Radius(m)	4.5	4.5
Seating Capacity	5 Persons	4 Persons
Boot Space(L)^#	214
#VDA method.

Engine

	PETROL	CNG
Engine Type	K10C	K10C CNG
Fuel type	Petrol	Petrol + CNG
Piston Displacement (cc)	998	998
Maximum Power (kW@rpm)	49 kW @ 5500 rpm	41.7 kW @ 5300 rpm (CNG Mode) 48 kW @ 5500 rpm (Petrol Mode)
Maximum Torque (Nm@rpm)	89 Nm @ 3500 rpm	82.1 Nm @ 3400 rpm (CNG Mode) 89 Nm @ 3500 rpm (Petrol Mode)
Emission Standard	BS VI	BS VI
Fuel Tank Capacity(L)	27	27 (Petrol Mode) 55 (CNG Mode) (Water Equivalent)

Transmission

	PETROL	CNG
Transmission Type	5MT/AGS	5MT

Suspension

	PETROL	CNG
Front	Mac Pherson Strut with Coil Spring	Mac Pherson Strut with Coil Spring
Rear	Torsion Beam with Coil Spring	Torsion Beam with Coil Spring

Tyre

	PETROL	CNG
Tyre Size	145/80 R13	145/80 R13

Brakes

	PETROL	CNG
Front	Disc	Disc
Rear	Drum	Drum

Get A Quote

I have read and understood the disclaimer

Disclaimer: I agree that by clicking the 'Submit' button below, I am explicitly soliciting a call from Maruti Suzuki India Ltd. or its partners on my 'Mobile' in order to assist me with the selection of a car. I confirm that details entered here are mine and shall be used by Maruti Suzuki India Ltd. or its partners to contact me.

OTP is sent successfully!

Please verify your number through One Time Verification Pin (OTP) sent on your Mobile number

Resend OTP

Get A Quote+

About Us
Know Our Dealership

about us

Situated on the Nagai Bypass Road, Vasan Nagar, Pillai & Sons Motor Company, Needamangalam, Thiruvarur, is a well-known Maruti Suzuki Arena outlet in the area. The outlet was established with an aim to improve accessibility for people in the region to buy new cars. Pillai & Sons Motor Company promises to deliver an enhanced car buying experience to customers. The outlet is equipped with 3S facilities to ensure a hassle-free journey throughout. The Maruti Suzuki Arena outlet is perfectly complemented with a team of well-trained professionals who are always ready to curate personalised experiences for all customers, tailored to meet their individual needs.
Pillai & Sons Motor Company Pvt Ltd was founded in 1982 and has been in the automobile sector ever since its inception. In 1997, Pillai & Sons Motor Company Pvt Ltd began its journey as an authorised Maruti Suzuki dealership in Thanjavur, Tamil Nadu. Within a short period of time, the dealership expanded by leaps and bounds, and today, has a presence that spreads across multiple locations in Chennai and central Tamil Nadu.

Know us

Welcome to Pillai, Maruti Suzuki ARENA showroom at Needamangalam in Thiruvarur where you will find the complete range of Maruti Suzuki cars, including Hatchback, Sedan, Suv or Van. As a reputed car dealership in Thiruvarur, Pillai, Needamangalam, Thiruvarur focuses on delivering a great car buying experience.

When you search for a ‘Maruti Suzuki car dealership near me’, you can rest assured that Pillai at Needamangalam in Thiruvarur will provide you with all the information and assistance you need to make a well-researched choice.

From exploring a wide range of accessories to the highest value offers, visit Pillai and check out the range of cars – from Dzire or Swift or Wagon R or Alto K10 to Celerio or S-presso or Ertiga or Brezza or Eeco in Thiruvarur along with on-road price and loan EMI.
Look through the Hatchback, Sedan, Suv or Van at our Maruti Suzuki ARENA outlet to book a test drive and book your favourite car today!

You can also visit the digital showroom of Pillai, Maruti Suzuki ARENA in Needamangalam. Filter your search as per your preferences for the Dzire or Swift or Wagon R or Alto K10 or Celerio or S-presso or Ertiga or Brezza or Eeco of your choice. Avail of these services online when you buy your new Maruti Suzuki ARENA car. You can also check out the latest offers & discounts and the wide range of accessories being offered at Pillai Maruti Suzuki ARENA.

Our Team

Mr. N. Srinivasan

Managing Director

CONTACT US

Maruti Suzuki ARENA, Needamangalam

Maruti Suzuki ARENA, Needamangalam
Pillai & Sons Motor Company
Survey no 121/3, Kottaiyur, Needamangalam, Tamil Nadu 614404

OPENING HOURS

Mon - Sun: 9 AM – 7 PM

+918071037011

+918037530091

customer testimonials

This was the best car buying experience I have ever had.

Mr Rajeev

I loved this showroom. The staff was so patient and clarified all my doubts, even after I told them that I was just browsing.

Mr Shubham

This was my first car buying experience, and thanks to the team here, it was unforgettable.

Mr Vishnu

Car Range

Safety

Infotainment

Comfort & Convenience

Exteriors

Interiors

Dimensions

Engine

Transmission

Suspension

Tyre

Brakes

Exteriors

Interiors

Comfort &Convenience

Central Consol & Instrument Panel

Safety & Security

New Technology

Dimensions

Engine

Transmission

Suspension System

Weight(kg)

Capacity

Power Steering

Tyres

Brakes

EXTERIOR

INTERIORS

SAFETY & SECURITY

INFOTAINMENT

COMFORT & CONVENIENCE

DIMENSIONS

ENGINE

TRANSMISSION

WEIGHT

Brakes

SUSPENSION

TYRES

Comfort

Instrument Panel & Console

Interior

Exterior

Safety & Security

Facilities On Board

Dimension & Weight

Engine(Petrol and CNG)

Transmission

Brake/Chassis

INTERIORS

EXTERIOR

INSTRUMENT CLUSTER

COMFORT & CONVENIENCE

INFOTAINMENT SYSTEM

SAFETY & SECURITY

**SUZUKI CONNECT

Dimension

Engine

Drive & Transmission

Break

Suspension

Weight

Exteriors

INTERIORS

SAFETY & SECURITY

AUDIO & ENTERTAINMENT

COMFORT & CONVENIENCE

Dimensions

ENGINE

TRANSMISSION TYPE

WEIGHT

EMISSION TYPE

BRAKE

SUSPENSION

WHEEL & TYRE SIZE³

Interiors

Comfort

Infotainment System

Safety and Security

Exterior

WHEEL & TYRE SIZE^³
